Laser cleaner
AL-C 500W Laser rust remover
AL-C series laser cleaning machine shows you the most environmental ,highest efficiency ,latest cleaning technology. It represents the first international level .
![](/template/asm/index/asm_res/image/youtube.gif)
Raycus is China’s top brand in pulsed type laser source which can assure the powerful
cleaning effect and it doesn’t hurt the base material .
Applications :
It is used for cleaning rust ,oil and paint .Includes oxide removal ,mold cleaning ,coating removal, weld pre-treatment, gluing pre-treatment surface cleaning ,surface preparation, tool cleaning, cultural relic restoration, precise cleaning ,oil removal ,grease stain removal, paint removal .
Our machine’s Advantages :
Laser cleaning machine is a new generation of surface cleaning of high-tech products. Easy to install, control and automatic. Easy to operate, turn on the power, open the device, then you can begin no chemical reagents, no media, dust-free, anhydrous cleaning, auto focus, fit surface cleaning, cleaning the surface cleanliness advantages, to clear the surface resin, Oil, dirt, dirt, rust, coating, coating, paint.
1.It’s laser source is of top brand ,the laser beam is even and powerful .
2.No contact cleaning ,no chemical abluent, save money
3.High speed and high efficiency .Not need any polish ,save time .
4.Safe and stable ,flexible using ,fiber laser source can assure long time service .
Parameters:
Item model | AL-C50 | AL-C100 | AL-C200 | AL-C300 | AL-C500 | |
Laser | Fiber(Raycus) Fiber(IPG)/Fiber (JPT) | |||||
Laser power | 50W | 100W | 200W | 300W | 500W | |
Laser length | 1064nm | |||||
Frequency | 20-100KHz | 20-200KHz | 20-50KHz | 20-50KHz | 20-50KHZ | |
Cooling way | Air cooling | Water cooling | Water cooling | Water cooling | ||
Cooling water | ─────── | Purified water | Purified water | |||
Water temperature | ─────── | 19℃ | 19℃ | |||
Machine Size | 980X830X1060mm | 800X1250X1250mm | 1650*1250*1250mm | |||
gross weight | 150kg | 150kg | 270kg(include water cooler) | 420KG(include water cooler) | ||
Whole Power | 350W | 600W | 1000W | 1500W | 2500W | |
Scan width | 10-60mm | |||||
Use way | handheld or automatic | |||||
Work temperature | 5-40℃ |
